Nowadays, we use Jinan remote control rolling shutter door in many places. We almost all know about the function and benefits of this rolling shutter door. What are the maintenance methods for the remote control failure of rolling shutter door?

1、電動機不動或轉速慢此故障原因一般是線路斷路、電機燒損、停止按鈕沒復位、限位開關動作、負載較大等引起。

1. The motor does not move or the speed is slow. The fault is generally caused by circuit break, motor burning, stop button not reset, limit switch action, heavy load, etc.

處理方法：檢查線路、并接通;更換燒損電機;更換按鈕或重復按動幾次; 撥動限位開關滑塊使它脫離微動開關觸點， 并調整微動開關位置;檢查機械部分 有無卡阻，若有則清理卡阻清理障礙物。

Treatment methods: check the circuit and connect it; replace the burnt motor; replace the button or press it repeatedly; move the slide of the limit switch to make it separate from the contact of the microswitch and adjust the position of the microswitch; check whether the mechanical part is jammed, and clean up the obstruction if any.

2、控制失效故障發生的部位及原因：.繼電器(接觸器)觸點粘死、行程微動開關失效 或觸片變形、滑塊緊定螺釘松、靠板螺絲松使靠板移位，使滑塊或螺母不能隨絲 桿轉動而移動、限位器傳動齒輪破損、按鈕上、下鍵卡死。

2. The parts and causes of control failure failure are as follows: the contact of relay (contactor) is stuck, the travel microswitch is invalid or the contact piece is deformed, the locking screw of slide block is loose, the screw of backup plate is loose, so that the slider or nut can not move with the screw rod rotation, the transmission gear wheel of limiter is damaged, and the up and down keys of button are stuck.

處理方法：更換繼電器(接觸器);更換微動開關或觸片;緊定滑塊螺釘并 使靠板復位;更換限位器傳動齒輪;更換按鈕。

Treatment methods: replace the relay (contactor); replace the microswitch or contact piece; tighten the slider screw and reset the backup plate; replace the transmission gear of the limiter; replace the button.

3、手拉鏈不動 故障原因：環形鏈條堵住十字槽;棘爪無脫離棘輪;壓鏈架卡死。

3. The cause of the failure of the hand zipper is: the ring chain blocks the cross groove; the pawl is not detached from the ratchet wheel; the chain holder is stuck.

處理方法：理順環形鏈條;調整棘爪與壓鏈架相對位置;更換或潤滑銷軸。

Treatment method: straighten out the ring chain; adjust the relative position between the pawl and the chain holder; replace or lubricate the pin shaft.

濟南遙控卷簾門

Jinan remote control rolling shutter door

4、電機振動或噪聲較大 故障原因：剎車盤不平衡或斷裂;剎車盤無緊固;軸承失油或失效;齒輪嚙合不順、失油或磨損嚴重;電機電流聲或振動。

4. The causes of motor vibration or noise are as follows: the brake disc is unbalanced or broken; the brake disc is not fastened; the bearing is lost oil or failure; the gear meshing is not smooth, oil loss or serious wear; the motor current sound or vibration.

處理方法：更換剎車盤或重新調整平衡;緊固剎車盤螺母;更換軸承;修配電機軸輸出端齒輪、潤滑或更換;檢查電機，如電機壞損則更換。

Treatment methods: replace the brake disc or readjust the balance; tighten the brake disc nut; replace the bearing; repair the motor shaft output gear, lubrication or replacement; check the motor, if the motor is damaged, replace it.

以上就是富強門業為大家介紹的關于濟南遙控卷簾門的全部內容，希望可以幫助到大家，如果有需要可以聯系我們或者關注我們公司網站：http://www.kmmhwl.com我們期待您的光臨。

The above is all about Jinan remote control rolling shutter door introduced by Fuqiang door industry. I hope it can help you. If you need, you can contact us or pay attention to our company website: http://www.kmmhwl.com We look forward to your coming.
