1、先參考接線端子接線圖，了解每個端子的作用及接線要求，再正確接線;確認接線無誤后，用500V兆歐表或搖表測試絕緣電阻;要求電源接線子電機接線端子對機殼及相互間絕緣電阻值不小于300MΩ;若絕緣電阻符合規定方可進行通電調試工作。
1. First refer to the wiring diagram of the wiring terminal to understand the function and wiring requirements of each terminal, and then connect correctly; After confirming that the wiring is correct, test the insulation resistance with 500V megger or megger; It is required that the insulation resistance between the power connector and the motor terminal to the casing and each other shall not be less than 300m Ω; If the insulation resistance meets the requirements, power on commissioning can be carried out.
2、接通電源查看“正常”指示燈是否亮，若不亮(控制回路沒電)應調換電源進線中任意兩相;手動控制卷簾門上行、下行、停止及行程開關的調整;在無火警的情況下，按“上”按鈕，卷簾門應下行;按“停”按鈕，卷簾門應停止運行。試運行時，有可能上、下不符，此時只需任意調換兩根起閉機的三相接線即可。隨后試同運行方向相對應的限位是否起作用(用手直接觸動微動開關)，不起作用時應調換限位接線;接著調整好行程開關位置，使防火卷簾門開閉到位。
2. Turn on the power and check whether the "normal" indicator light is on. If it is not on (the control circuit is dead), replace any two phases in the power incoming line; Manually control the up, down, stop and travel switch adjustment of the rolling shutter door; In case of "no fire alarm", press the "up" button, and press the "down" button; Press the "stop" button to stop the rolling shutter door. During trial operation, there may be inconsistency between the upper and lower parts. At this time, it is only necessary to arbitrarily replace the three-phase wiring of two hoists. Then test whether the limit corresponding to the operation direction works (touch the microswitch directly by hand). If it doesn't work, replace the limit wiring; Then adjust the position of the travel switch to make the fireproof rolling shutter door open and close in place.

卷簾門組成防火卷簾門主要由防火卷簾簾體和電控系統。電控系統包括電控箱、熔斷器、防火電機。簾面采用無機耐火布、硅酸鋁纖維毯、防輻射布和裝飾布經高溫線縫制而成，雙面用鍍鋅鋼制條夾制，確保簾布的抗風強度，底箱封板為鋼質鍍鋅，厚 度0.8㎜，無接縫。無縫鋼管，管壁外經除銹防腐處理。 導軌采用鋼質鍍鋅厚度1.2，采用分體復合制作。
The fire rolling shutter door is mainly composed of the fire rolling shutter body and the electric control system. The electric control system includes electric control box, fuse and fireproof motor. The curtain surface is made of inorganic refractory cloth, aluminum silicate fiber blanket, radiation protection cloth and decorative cloth through high-temperature thread. Both sides are clamped with galvanized steel strips to ensure the wind resistance of the curtain. The bottom box sealing plate is steel galvanized, with a thickness of 0.8mm and no joints. Seamless steel pipe, derusting and anti-corrosion treatment outside the pipe wall. The guide rail is made of steel with galvanized thickness of 1.2 and is made of split composite.
卷簾門可獨立控制并具有手動功能，與溫度熔斷裝置聯動，與消防中控室直接進行聯動。實現煙感報警，卷簾自動下降地面1.5-1.8m高度，延時180秒(可 調)然后在下降關閉。當下降時遇到障礙物可停止下降并上升?？蓪崿F(xiàn)煙感報警一次下滑，溫感報警二次下滑，且溫感報警后可停止二次下滑，可在一個系統內互相轉換。卷簾配斷鏈保護裝置，以保護卷簾的可靠，確保安 全。
The rolling shutter door can be controlled independently and has a manual function. It is linked with the temperature fuse device and directly linked with the central fire control room. Realize the smoke alarm, and the rolling shutter will automatically descend to the height of 1.5-1.8m on the ground, with a delay of 180 seconds (adjustable), and then close when descending. When falling, it can stop falling and rise when encountering obstacles. It can realize the primary decline of smoke alarm and the secondary decline of temperature alarm. After the temperature alarm is eliminated, the secondary decline can be stopped and can be converted to each other in one system. The roller shutter is equipped with chain breaking protection device to protect the reliability of the roller shutter and ensure safety.
卷簾門電控箱注意事項：1、為安 全起見，控制器必 須接好地線!2、限位開關沒有調整以前在無人監控狀態下，電控箱不可處于通電狀態;3、電控箱正式投入運行后，每月應進行一次運行檢查;4、按鍵指令門不動作，先檢查三相電源是否缺相，三相電源進線的相序是否接錯，停止鍵是否接在常開觸點上。
Precautions for electric cabinet of rolling shutter door: 1. For safety, the controller must be grounded! 2. Before the limit switch is adjusted, the electric control box cannot be powered on under the condition of unattended monitoring; 3. After the electric cabinet is officially put into operation, the operation inspection shall be conducted once a month; 4. If the key command door does not act, first check whether the three-phase power supply lacks phase, whether the phase sequence of the incoming line of the three-phase power supply is connected incorrectly, and whether the stop key is connected to the normally open contact.
