車庫門行程的調整從多方面開始
來源：http://www.kmmhwl.com 日期：2022-05-28 發布人：
其實在使用車庫門的情況下，都要對它進行調節的，根據我們?cè)缙诘恼{(diào)節工作，后期在運轉的情況下才會更便捷，但是許多人對于并沒有太大的了解，接下來就來講講車庫門行程的調整從多方面開始是怎樣的吧。
In fact, when the garage door is used, it should be adjusted. According to our early adjustment work, it will be more convenient in the later operation. However, many people do not know much about it. Next, let's talk about the adjustment of the garage door travel from many aspects.
1.行程限位開關的調整，門的電源初步選擇
1. adjustment of travel limit switch and preliminary selection of door power supply
該調整環節為一級程序設計，可通過對開閉行程限位的測量，監測力距，選擇開門關門環節力的默認設置。
The adjustment link is a level-1 program design, which can monitor the force distance and select the default setting of the force in the door opening and closing link through the measurement of the opening and closing stroke limit.
2、流程如下：
2. The process is as follows:
(1)插上電源后，處于待機狀態。此時主板狀態指示燈常亮。如果主板狀態指示燈不亮，請檢查電源模塊是否連接。
(1) After the power is plugged in, it is in standby mode. At this time, the motherboard status indicator is always on. If the motherboard status indicator is not on, check whether the power module is connected.
(2)車庫門行程限位的調整
(2) Adjustment of garage door travel limit
按住電控箱功能鍵3秒，直到狀態顯示燈慢閃（操作顯示燈滅），松開功能鍵，再用“”鍵和“-”鍵調節門到合適的位置（按“”鍵開門，按“-”鍵關門），按電控箱上的功能鍵確認并保持，狀態顯示燈快閃后熄滅出，并自動變成慢閃的運行燈，（此時可以進入另一個過程——關閉行程限位調整）。
Press and hold the function key of the electric control box for 3 seconds until the status display lamp flashes slowly (the operation display lamp is off), release the function key, and then use the "" and "-" keys to adjust the door to the appropriate position (press the "" key to open the door, press the "-" key to close the door), press the function key on the electric control box to confirm and maintain, the status display lamp flashes quickly and then goes out, and automatically becomes a slow flashing running lamp (at this time, you can enter another process - turn off the travel limit adjustment).
（3）當行程限位開關關閉，運行燈慢閃（狀態燈滅）時，按“減”鍵，門體下降到合理位置（可以按“”鍵和“-”鍵點動調整）。按功能鍵確認預約，運行燈閃爍數次后熄滅。
(3) When the travel limit switch is closed and the running light flashes slowly (the status light is off), press the "minus" key to lower the door body to a reasonable position (you can press the "" key and "-" key for inching adjustment). Press the function key to confirm the appointment, and the running light flashes for several times and then goes out.
(4)行程調節過程在電控箱自動測試和啟閉力默認設置的幫助下關閉后，門體可以自行進行啟閉活動，從而實現過程監控和默認設置強制，然后狀態燈長亮。以上調整已實現基本調整，車庫門可以正常操作。
(4) After the stroke adjustment process is closed with the help of the automatic test of the electric control box and the default setting of the opening and closing force, the door body can carry out the opening and closing activities by itself, so as to realize the process monitoring and the default setting force, and then the status light is on for a long time. The above adjustments have achieved basic adjustment, and the garage door can operate normally.
3、開合力的人力調整
3. Manpower adjustment of opening force
濟南車庫門認為該環節為2級程序設計，一般情況下無需調整?？蛇M(jìn)行調整，滿足各類客戶對電機開門和停止的靈敏性和可靠性，以及受阻回彈功能的靈敏性和可靠性的各種需求。
Jinan garage door thinks that this link is a level 2 program design, which generally does not need to be adjusted. It can be adjusted to meet various customers' requirements for the sensitivity and reliability of motor door opening and stopping, as well as the sensitivity and reliability of blocked rebound function.
(1)功率分析與說明
(1) Power analysis and description
手動調節的啟閉力是指在電機自動測得的啟閉力的基礎上增加的力。電機默認設置為1檔關力，2檔開門。
The manually adjusted opening and closing force refers to the increased force based on the opening and closing force automatically measured by the motor. The default setting of the motor is the closing force of gear 1 and the door opening of gear 2.
(2)調整環節：
(2) Adjustment phase:
長按“P”鍵約6秒，紅燈綠燈長同時亮?xí)r，先設置開門力，按“”鍵增大，按“-”鍵減小.綠燈慢閃的次數就是當前的力度等級。選擇后按“P”鍵確認，保留。功率調節自行關閉時，（紅綠燈常亮的情況下），按“”鍵增加“-”鍵減少，紅燈表示多少慢閃次數為當前值，按“P”鍵確認，按住退出進程。紅燈變?yōu)槌Ａ痢?/div>
Press and hold the "P" key for about 6 seconds. When the red and green lights are on at the same time, set the door opening force first, press the "" key to increase, and press the "-" key to decrease The number of slow flashes of the green light is the current strength level. Press "P" key to confirm after selection and keep. When the power regulation turns off automatically (when the traffic light is always on), press "" to increase "-" to decrease. The red light indicates that the number of slow flashes is the current value, press "P" to confirm, and press and hold to exit the process. The red light goes on.
4、濟南車庫門手動控制器的對碼與取消
4. Code checking and cancellation of Jinan garage door manual controller
(1)車庫門取消代碼
(1) Garage door cancellation code
長按對碼鍵約三秒，直到顯示燈熄滅，實現對碼取消過程。
Press and hold the code matching key for about three seconds until the display light goes out to realize the code cancellation process.
(2)車庫門配套
(2) Garage door matching
按下控制器的對碼鍵，對碼顯示燈長亮，再按手動無線遙控器上需要配對的功能鍵（A或B），對碼顯示燈控制器將從長亮變?yōu)殚W爍。
Press the code matching key of the controller, the code matching display light will be on for a long time, and then press the function key (a or b) to be paired on the manual wireless remote control, and the code matching display light controller will change from long light to flashing.
車庫門行程的調整的相關內容就是以上講解了，您可以來關注我們的網站www.kmmhwl.com，選購您所需要的門，當然有問題可以隨時聯系我們?yōu)槟獯穑?/div>
The adjustment of garage door travel is explained above. You can follow our website www.jnzxmy COM, choose the door you need. Of course, if you have any questions, you can contact us at any time to answer them for you!
